DZOFILM Arles Zoom 65-180mm T2.6 FF Cine Zoom Lens ARRI PL Canon EF Metric DZO DZO-AZ65180M

Brand: DZO
Product Code: DZO-AZ65180M
Availability: In Stock

$4,299.00

Description
Reviews (0)

Key Features

Covers Full Frame | T2.6 Max Aperture
Painterly Look with Rich Natural Colors
0.8 MOD Gearing | 270° Focus Rotation
95mm Front Outside Diameter
Interchangeable PL Mount
16-Blade Iris, Smooth Circular Bokeh
Soft, Low-Contrast Look at Wide Aperture
Immersive Look with Minimal Breathing
Dual Focus Marks in Feet and Meters
Robust Aluminum Alloy Build

Cinematic, Painterly Look

Expanding the existing Arles series of prime lenses, the Arles Zoom 65-180mm T2.6 FF Cine Lens from DZOFilm combines high optical quality and mechanical precision in a compact form. This full-frame zoom lens features a constant T2.6 maximum aperture, 16-blade iris, soft, natural bokeh, ARRI PL and Canon EF mounts, and the same cinematic, painterly depth as the Arles primes.

Telephoto Parfocal Zoom

This Arles 65-180mm zoom covers an essential focal length range with a 2.8x ratio, maintaining a constant minimum focus distance of 35" and a maximum magnification of 0.22x at the telephoto end. When paired with the separately available Arles 25-75mm zoom, the two lenses overlap to cover a truly wide 25-180mm range. The parfocal design maintains focus throughout the zoom range, and the consistent gear positions and similar size enable quick lens changes, even when using a matte box and lens control motors.

Full-Frame Coverage

Maintaining a fast, constant T2.6 aperture from 65mm to 180mm, this Arles zoom lens covers full-frame sensors up to a 43.5mm image circle, maximizing light transmission and creating expansive, three-dimensional imagery with rich textural depth.

Painterly Rendering

A custom, low-saturation blue coating helps the Arles zooms create a modern tone while minimizing flares and ghosting. Their warm, natural color science renders natural skin tones that integrate easily with the DZOFilm ecosystem.

Interchangeable PL Mount

This ARRI PL-mount lens has a short rear flange design, enabling it to be used with a separately available Canon EF mount, offering compatibility with a wide range of cine-style, mirrorless, and DSLR cameras. When paired with Octopus adapters, autofocus adapters, or VND adapters, it seamlessly adapts to mirrorless systems including L-Mount and Canon RF, DJI DX, FUJI X, Nikon Z, and Sony E mounts.

Consistency Across Series

A 95mm outer diameter lets you incorporate different matte boxes or filters in your camera configuration. Each Arles zoom lens has a cine-style design with 0.8 MOD focus, iris, and zoom gears. The focus ring rotates 270°, and the iris ring 100° for precise manual adjustments.

UPC: 842463106598

Items Included
DZOFilm Arles Zoom 65-180mm T2.6 FF Cine Lens (ARRI PL/Canon EF)
ARRI PL Mount
Canon EF Mount
Front Cap
PL Rear Cap
Shim Set
Support Base
Support Rod

Key Specs

Focal Length	65 to 180mm
Maximum Aperture	T2.6
Lens Mount	Interchangeable Mount with Included ARRI PL
Lens Format Coverage	Full-Frame (43.5 mm Image Circle)
Filter Thread	86 mm
Image Stabilization	No
Electronic Communication	No

Focal Length	65 to 180mm
Maximum Aperture	T2.6
Lens Mount	Interchangeable Mount with Included ARRI PL
Lens Format Coverage	Full-Frame (43.5 mm Image Circle)
Focus Scales	Metric, Imperial
Filter Thread	86 mm
Zoom Ratio	2.8x (Manual)
Minimum Focus Distance	From Camera Sensor: 35" / 89 cm
Aperture/Iris Blades	16
Image Stabilization	No
Gear Standard	Focus, Iris: 0.8 MOD
Gear Rotation	Focus: 270° Zoom: 100°
Electronic Communication	No
Diameter	Front: 3.7" / 95 mm
Length	7.5" / 19 cm
Weight	3.92 lb / 1.78 kg
